Germinal

Germinal is a complete pipeline for de novo, epitope-targeted antibody design (single-domain VHHs and scFvs), from Mille-Fragoso et al., 2025. This toolkit wraps it as one tool, germinal-design, that runs a full design campaign against one target per call: AF2-Multimer hallucination, AbMPNN sequence redesign, and structure validation with PyRosetta interface filtering.

Arc Institute

Proto is not affiliated with Arc Institute. This toolkit is open source and builds on the implementation produced by this organization. Product names, logos, and trademarks are the property of their respective owners.

---

GitHub 202 GitHub 202 Preprint Preprint Cite Cite Tool Source Tool Source Open as Notebook Open as Notebook

SantiagoMille/germinal

Codebase for Germinal, a broadly enabling generative pipeline for efficient generation of epitope-targeted de novo antibodies.

202 stars

View repo

Efficient generation of epitope-targeted de novo antibodies with Germinal

Luis S. Mille-Fragoso, Claudia L. Driscoll, … Xiaojing J. Gao

bioRxiv (2025)

Read preprint

@article{mille_fragoso_2025_germinal,
  title={Efficient generation of epitope-targeted de novo antibodies with Germinal},
  author={Mille-Fragoso, Luis S. and Driscoll, Claudia L. and Wang, John N. and Dai, Haoyu and Widatalla, Talal and Zhang, Jim L. and Zhang, Xiaowei and Rao, Bing and Feng, Liang and Hie, Brian L. and Gao, Xiaojing J.},
  journal={bioRxiv},
  year={2025},
  doi={10.1101/2025.09.19.677421},
  url={https://www.biorxiv.org/content/10.1101/2025.09.19.677421},
  publisher={Cold Spring Harbor Laboratory}
}

Copy citation

proto-bio/proto-tools/proto_tools/tools/binder_design/germinal

View source

Open Notebook

Open notebook

Function	Description
run_germinal_design()	De novo epitope-targeted antibody design (VHH or scFv) using the Germinal pipeline (GPU)	Docs Source

License: Germinal’s own code is licensed under Apache-2.0, but it runs as a pipeline that depends on bundled components and model weights under separate license terms, including non-commercial or restricted-use terms. The bundled model weights are licensed under CC-BY-4.0. As a whole the pipeline has restrictions around commercial use and may require explicit attribution when utilized.

Bundled dependencies, each under its own license:

• PyRosetta: Custom (PyRosetta Software License)
• IgLM: Custom (IgLM License)

Review the code license and the model weights license before any commercial use or redistribution.

Background

Germinal produces epitope-targeted antibody binders computationally from a target structure and an epitope definition, an alternative to animal- or library-based discovery such as immunization, phage display, and hybridoma screening. The Germinal publication reports experimental binding success rates of 4 to 22 percent across the benchmarks it evaluates.

Germinal combines ColabDesign with AlphaFold2-Multimer hallucination, antibody language-model gradients (IgLM, AbLang), AbMPNN sequence redesign (Dreyer et al., 2023), and structure validation against Chai-1, AlphaFold3, or Protenix, followed by PyRosetta interface scoring and a multi-stage filter cascade. Relative to earlier antibody hallucination methods, Germinal additionally applies epitope-hotspot conditioning (the optimization is constrained so the binder contacts the user-specified residues), antibody language-model guidance (biasing designs toward sequences resembling natural antibodies), an early filtering stage that discards weak candidate designs before the computationally expensive structure-prediction step, and a structure-validation model that is independent of the model used during hallucination.

Tools

Germinal Antibody Design (germinal-design)

Runs one complete Germinal antibody-design campaign against a single target. Given a target PDB, a target chain, and the epitope hotspot residues, it runs a fixed (version-pinned) copy of the upstream run_germinal.py script, repeating hallucination, then AbMPNN redesign, then structure validation and filtering until either max_trajectories or max_passing_designs is reached, and returns ranked designs with predicted complex structures and per-design metrics (interface pTM, pAE, pDockQ2, pLDDT, and others). Upstream configuration defaults are preserved exactly; the only change is setting the structure-validation model (structure_model) to Chai-1, because Chai-1 installs automatically.

API Reference

Source

Input: GerminalInput

target_pdb · Structure · required

Target structure. Accepts a file path, raw PDB/CIF content string, Structure object, or a dict in the shape produced by Structure.model_dump(mode='json'). Must include a chain matching target_chain.

Show Structure

structure · string · required

Raw structure content in PDB or CIF format.

structure_format · string

Format of the content string (auto-detected if omitted).

b_factor_type · BFactorType · default: "unspecified"

What the B-factor column represents.

source · string

Optional source identifier (filepath or tool name).

metrics · Metrics

Associated metrics (e.g., pLDDT, pTM scores, per-chain lists, pairwise matrices). None values are stripped at construction.

target_chain · string · default: "A"

Chain ID(s) of the target. Single letter (e.g. "A") or comma-separated for multi-chain targets (e.g. "A,B").

binder_chain · string · default: "B"

Chain ID assigned to the designed binder. Default "B" (matches Germinal’s source convention in configs/target/pdl1.yaml).

hotspots · List[string]

Hotspot residues on the target in "<chain_letter><resnum>" format (e.g. ["A37", "A39", "A41"]). These are the residues the designed binder is forced to contact.

target_name · string

Short identifier for this target. Used as the Hydra target=<name> selector and as a prefix in output filenames. If None, the inference layer derives one from a hash of the PDB content.

hotspot_residue · string

Optional single residue (e.g. "W40") used as the Chai-1 contact-restraint anchor. Mirrors Germinal’s hotspot_residue field in configs/target/*.yaml.

Source

Config: GerminalConfig

design_type · enum · default: "vhh"

Run preset selector.

Available options: vhh, scfv

max_trajectories · integer · default: "10000"

Hard cap on total trajectories before stopping.

max_hallucinated_trajectories · integer · default: "1000"

Cap on trajectories that complete the hallucination stage (before MPNN refinement).

max_passing_designs · integer · default: "100"

Stop early once this many designs pass all final filters.

structure_model · enum · default: "chai"

Cofolding backend for structure validation. Default "chai" (auto-installed); "af3" and "protenix" require user-provisioned weights/env (see README → Backend Configuration).

Available options: chai, af3, protenix

plddt_threshold · number

Override final external_plddt (VHH: > 0.87, scFv: > 0.85). Distinct from upstream’s in-loop plddt_threshold save filter — use germinal_overrides.

iptm_threshold · number

Override final external_iptm (preset: > 0.74).

ipae_threshold · number

Override final external_pae in Å (VHH: < 7.5, scFv: < 8).

ptm_threshold · number

Override final external_ptm (preset: > 0.84).

pdockq2_threshold · number

Override final pdockq2 (preset: > 0.23).

germinal_overrides · Dict[string, any]

Arbitrary Hydra overrides for run_germinal.py (e.g. {"logits_steps": 100, "weights_iptm": 1.0}). Applied verbatim as <key>=<value> CLI args.

filter_overrides · Dict[string, Dict[string, Dict[string, any]]]

Override filter YAML values. Schema: {"initial" | "final": {<filter_name>: {"value": <v>, "operator": <op>}}}. Merged on top of the design_type preset.

output_dir · string

Optional persistent output directory. If unset, a temp dir is used and discarded after the call.

verbose · integer · default: "0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

device · string · default: "cuda"

Device for the Germinal subprocess. Forced to "cuda"; CPU is not supported by the upstream pipeline.

timeout · integer

Maximum execution time in seconds. None waits indefinitely.

seed · integer

Random seed. When set, tools run reproducibly up to small GPU float noise (see BaseToolOutput.approx_equal), and the seed participates in cache keys. When None, cacheable seed-sensitive tools skip cache until seeded.

Source

Output: GerminalOutput

designs · List[GerminalDesign]

All produced designs across the accepted, redesign_candidate, and trajectory stages.

Show GerminalDesign

sequence_heavy · string · required

Heavy chain (or VHH) amino-acid sequence.

sequence_light · string

Light chain sequence (scFv only).

structure · Structure · required

Predicted binder + target complex.

metrics · GerminalDesignMetrics · required

Per-design quality metrics.

stage_passed · enum · required

Highest pipeline stage this design reached.

design_id · string · required

Germinal’s internal design identifier ("<target>_<type>_s<seed>" for trajectory-only designs, "<target>_<type>_s<seed>_abmpnn_<j>" after AbMPNN redesign).

trajectory_index · integer · required

Trajectory seed (parsed from _s<seed>). Germinal uses the seed as its unique trajectory identifier.

mpnn_index · integer · required

AbMPNN sample index (1-based; 0 for trajectory-only designs that never reached the redesign stage).

pipeline_stats · Dict[string, integer]

Per-stage counts from Germinal’s failure_counts.csv (trajectories attempted, designs accepted, and per-filter failure counts).

Metrics

Metric	Type	Range	Availability
plddt	float	0.0 to 1.0	always
ptm	float	0.0 to 1.0	always
i_ptm	float	0.0 to 1.0	always
i_pae	float	≥ 0.0	always
pae	float	≥ 0.0	always
loss	float	unbounded	always
lm_ll	float	unbounded	always
helix	float	unbounded	always
beta_strand	float	unbounded	always
clashes	int	≥ 0.0	after filtering
sc_rmsd	float	≥ 0.0	after filtering
binder_near_hotspot	bool	unbounded	after filtering
cdr3_hotspot_contacts	int	≥ 0.0	after filtering
percent_interface_cdr	float	0.0 to 1.0	after filtering
interface_shape_comp	float	0.0 to 1.0	after filtering
interface_hbonds	int	≥ 0.0	after filtering
surface_hydrophobicity	float	0.0 to 1.0	after filtering
interface_hydrophobicity	float	≥ 0.0	after filtering
pdockq2	float	0.0 to 1.0	after filtering
external_plddt	float	0.0 to 1.0	after validation
external_iptm	float	0.0 to 1.0	after validation
external_ptm	float	0.0 to 1.0	after validation
external_pae	float	≥ 0.0	after validation
external_i_pae	float	≥ 0.0	after validation
external_i_plddt	float	0.0 to 1.0	after validation
external_plddt_binder	float	0.0 to 1.0	after validation
external_chain_ptm	float	0.0 to 1.0	after validation
external_binder_pae	float	≥ 0.0	after validation
external_aggregate_score	float	unbounded	after validation
ipsae	float	0.0 to 1.0	after validation
ipsae_pdockq2	float	0.0 to 1.0	after validation
lis_lis	float	unbounded	after validation
lis_lia	float	unbounded	after validation
binder_score	float	unbounded	after filtering
interface_packstat	float	0.0 to 1.0	after filtering
interface_dG	float	unbounded	after filtering
interface_dSASA	float	≥ 0.0	after filtering
interface_dG_SASA_ratio	float	unbounded	after filtering
interface_fraction	float	0.0 to 1.0	after filtering
interface_nres	int	≥ 0.0	after filtering
interface_hbond_percentage	float	0.0 to 1.0	after filtering
interface_delta_unsat_hbonds	int	≥ 0.0	after filtering
interface_delta_unsat_hbonds_percentage	float	0.0 to 1.0	after filtering
clashes_unrelaxed	int	≥ 0.0	after filtering
hydrophobic_patches_binder	int	≥ 0.0	after filtering
hydrophobic_patches_struct	int	≥ 0.0	after filtering
sap_score	float	unbounded	after filtering
cdr_sap	float	unbounded	after filtering
cdr_hotspot_contacts	int	≥ 0.0	after filtering
percent_interface_cdr3	float	0.0 to 1.0	after filtering
alpha_interface	float	0.0 to 1.0	after filtering
beta_interface	float	0.0 to 1.0	after filtering
loops_interface	float	0.0 to 1.0	after filtering
alpha_all	float	0.0 to 1.0	after filtering
beta_all	float	0.0 to 1.0	after filtering
loops_all	float	0.0 to 1.0	after filtering
n_framework_mutations	int	≥ 0.0	after filtering

Applications

This tool performs de novo therapeutic antibody discovery: generating epitope-targeted VHH or scFv binders against a chosen target. It requires only a target structure and an epitope definition, and produces a ranked set of designs with predicted complex structures and per-design quality metrics, ready for selection and experimental testing.

Usage Tips

• design_type selects the run preset. "vhh" (single-domain nanobody, the default) or "scfv"; each loads the upstream preset with different filter thresholds, so leave the *_threshold fields set to None to let the correct preset apply.
• Reduce max_trajectories when testing. The upstream default of 10000 corresponds to a run that takes hours to days; use a small value while testing, and set max_passing_designs below max_trajectories to stop early once enough designs pass the filters.
• structure_model selects the structure-validation model. Validation uses a model independent of the hallucination step. The published filter thresholds were calibrated against AlphaFold3, so acceptance rates may differ under the "chai" default and the *_threshold fields may need adjusting to match the reported rates.
• germinal_overrides passes additional settings to the underlying pipeline. Any upstream configuration option that is not exposed as a dedicated field can be supplied here as a <key>=<value> pair.

Toolkit Notes

These apply to every Germinal tool in this toolkit (germinal-design).

• Requires a GPU and can run for a long time. An NVIDIA GPU with at least 40 GB of GPU memory is required (at least 80 GB for scFv mode or targets longer than 250 residues); running on CPU is not supported. A full run with default settings takes hours to days, so reduce max_trajectories when testing.
• Structure-validation model setup varies. structure_model="chai" needs no manual setup. "af3" requires AlphaFold3 weights that you must request and install yourself (access is restricted; request it through DeepMind’s form) along with a container image. "protenix" requires a separate Protenix environment.
• Bundled dependencies carry their own licenses. The pipeline requires PyRosetta (academic, non-profit, and government use is governed by the University of Washington CoMotion license; commercial use requires a separate license; redistribution is not permitted; consult the current PyRosetta licensing page for terms and availability) and IgLM (academic, non-commercial use only); Chai-1 is Apache-2.0 and AbLang2 is BSD-3-Clause. See the License note above and the linked terms.
• One campaign per call. Each call is a single complete run against one target. To screen several targets, call the tool once per target (for example, in a loop) rather than expecting one call to process multiple targets at once.

Example notebook: See the full working example for a copy-paste-ready walkthrough.
