Using Optimizers

Run the built-in optimizers and chain them into multi-stage searches over biological sequences

An optimizer is the search engine of a program. On each step it asks the generators to propose candidate sequences, scores those candidates with the constraints, and keeps the ones that score best; over many steps the retained sequences move toward the design objective. A Program runs one or more optimizers and collects the final results.

This guide describes the optimizer interface, the built-in optimizers and what each is suited to, how to run one, and how to chain several into a multi-stage program. Custom optimizers are out of scope; the built-in set covers the common search strategies.

Open as a runnable notebook View as a Python script

The loop

Every optimizer is constructed the same way: it is given the constructs it designs, the generators that propose sequences, the constraints that score them, and a config that sets the search parameters. The optimizer then repeats a propose-score-select loop.

The generators and constraints are the same objects described in Using Generators and Using Constraints; the optimizer coordinates them. What differs between optimizers is the strategy by which proposals are generated and selected, and the parameters that govern it.

The built-in optimizers

MCMC

Metropolis-Hastings sampling: each proposal is accepted or rejected against a temperature schedule. A general-purpose local search.

Rejection Sampling

Draw a batch of candidates and keep those below an energy threshold. Useful for filtering and for a first enrichment stage.

Beam Search

Maintain a beam of partial sequences, extending and pruning them. Suited to autoregressive generation.

Cycling

Alternate between two providers, such as structure prediction and inverse folding. The Protein Hunter pattern.

Gradient

Differentiable optimization of position weights by gradient descent, following a soft-to-hard schedule.

Running an optimizer

The example below balances the composition of a 100 bp DNA insert with the MCMCOptimizer. The optimizer’s config sets the search budget: num_steps is the number of propose-score-select iterations, proposals_per_result is how many candidates are evaluated per step, and the temperature controls how readily worse proposals are accepted (higher is more exploratory).

python

from proto_language.core import Segment, Construct, Constraint, Program
from proto_language.constraint import gc_content_constraint
from proto_language.generator import RandomNucleotideGenerator, RandomNucleotideGeneratorConfig
from proto_language.optimizer import MCMCOptimizer, MCMCOptimizerConfig

# A 100 bp DNA insert, a random-mutation generator, and a GC-content objective.
insert = Segment(length=100, sequence_type="dna", label="insert")
construct = Construct([insert])

generator = RandomNucleotideGenerator(RandomNucleotideGeneratorConfig())
generator.assign(insert)

gc = Constraint(
    inputs=[insert],
    function=gc_content_constraint,
    function_config={"min_gc": 40, "max_gc": 60},
    label="gc_content",
)

# The config is where the search strategy is tuned.
optimizer = MCMCOptimizer(
    constructs=[construct],
    generators=[generator],
    constraints=[gc],
    config=MCMCOptimizerConfig(
        num_results=1,
        proposals_per_result=1,
        num_steps=100,
        max_temperature=1.0,
    ),
)

# A Program runs the optimizer and collects the result.
program = Program(optimizers=[optimizer], num_results=1)
program.run()

best = program.constructs[0].joined_sequences[0]
gc_pct = best.metadata["segments"]["insert"]["constraints"]["gc_content"]["data"]["gc_content"]
print(f"final sequence: {best.sequence}")
print(f"GC content:     {gc_pct:.1f}%")

Chaining optimizers into stages

A Program may run several optimizers in sequence. When the stages share the same Segment and Construct objects, the result sequences of one stage become the starting point of the next, so the design is refined incrementally rather than rebuilt. This is how a coarse, broad search is followed by a fine, narrow one.

The two stages below operate on a single 20 bp insert: rejection sampling first enriches it toward a wide 70-100% GC window, then MCMC refines it into a tight 80-90% window.

python

from proto_tools.transforms.masking import MaskingStrategy
from proto_language.optimizer import (
    RejectionSamplingOptimizer,
    RejectionSamplingOptimizerConfig,
)

# One construct is reused across both stages, so state carries over between them.
insert = Segment(length=20, sequence_type="dna", label="insert")
construct = Construct([insert])

# Stage 1: rejection sampling makes large moves to enrich GC content broadly.
gen1 = RandomNucleotideGenerator(
    RandomNucleotideGeneratorConfig(masking_strategy=MaskingStrategy(num_mutations=10))
)
gen1.assign(insert)
stage1 = RejectionSamplingOptimizer(
    constructs=[construct],
    generators=[gen1],
    constraints=[Constraint(inputs=[insert], function=gc_content_constraint,
                            function_config={"min_gc": 70, "max_gc": 100}, label="gc_enrich")],
    config=RejectionSamplingOptimizerConfig(num_samples=10, num_results=3),
)

# Stage 2: MCMC makes small moves to refine into a tighter window.
gen2 = RandomNucleotideGenerator(
    RandomNucleotideGeneratorConfig(masking_strategy=MaskingStrategy(num_mutations=1))
)
gen2.assign(insert)
stage2 = MCMCOptimizer(
    constructs=[construct],
    generators=[gen2],
    constraints=[Constraint(inputs=[insert], function=gc_content_constraint,
                            function_config={"min_gc": 80, "max_gc": 90}, label="gc_refine")],
    config=MCMCOptimizerConfig(num_results=1, proposals_per_result=20, num_steps=10, max_temperature=2.0),
)

# The program runs the stages in order on the shared construct.
program = Program(optimizers=[stage1, stage2], num_results=1)
program.run()

best = program.constructs[0].joined_sequences[0]
gc_pct = best.metadata["segments"]["insert"]["constraints"]["gc_refine"]["data"]["gc_content"]
print(f"final sequence: {best.sequence}")
print(f"GC content:     {gc_pct:.1f}%")

The model-backed optimizers

Two optimizers coordinate machine-learning tools rather than composition constraints, and so require a GPU. The CyclingOptimizer alternates between two providers; in the Protein Hunter program it cycles between structure prediction and inverse folding, each round refining the sequence toward a target fold. The GradientOptimizer pairs with PositionWeightGenerator to optimize a differentiable sequence by gradient descent, following a soft-to-hard schedule that sharpens a continuous sequence into a discrete one. Complete, runnable versions of both appear in the Example Programs.

Practical considerations

The search budget lives in the optimizer config: num_steps (or num_samples) sets how long the search runs, num_results sets how many designs are returned, and proposals_per_result sets how many candidates are evaluated per step. Start small while iterating, then scale up.

Multi-stage programs share state through object identity: the later optimizers must be given the same Segment and Construct instances as the earlier ones for the design to carry over. Constructing fresh segments for a later stage starts it from scratch instead.

Pass verbose=True in a config, or a custom_logging callable to the optimizer, to inspect the score of the best sequence at each step while tuning a search.
