AlphaFold DB

The AlphaFold Protein Structure Database is a public archive of protein structures predicted by AlphaFold2, maintained by Google DeepMind and EMBL-EBI and indexed by UniProt accession. The alphafold-db-fetch tool retrieves a single prediction record from the AlphaFold DB REST API, returning a parsed Structure (PLDDT B-factors, per-residue pLDDT and optional pAE on structure.metrics), the predicted sequence, organism and gene metadata, and the full JSON record. It runs on CPU and requires only network access.

Google DeepMind EMBL-EBI

License: AlphaFold DB retrieves data from the AlphaFold Protein Structure Database, distributed under CC-BY-4.0. Attribution to the AlphaFold Protein Structure Database is required when the data is redistributed. The client wrapper code is Apache-2.0-licensed. Please refer to the data terms for full terms.

Proto is not affiliated with Google DeepMind and EMBL-EBI. This toolkit is open source and builds on the implementations produced by these organizations. Product names, logos, and trademarks are the property of their respective owners.

---

GitHub 14.4k GitHub 14.4k Publication Publication Cite Cite Tool Source Tool Source Open as Notebook Open as Notebook Open on Proto Open on Proto

google-deepmind/alphafold

Open source code for AlphaFold 2.

14.4k stars

View repo

AlphaFold Protein Structure Database: massively expanding the structural coverage of protein-sequence space with high-accuracy models

Mihaly Varadi, Stephen Anyango, … Sameer Velankar

Nucleic Acids Research (2022)

Read paper

@article{varadi2022alphafold,
  title={AlphaFold Protein Structure Database: massively expanding the structural coverage of protein-sequence space with high-accuracy models},
  author={Varadi, Mihaly and Anyango, Stephen and Deshpande, Mandar and Nair, Sreenath and Natassia, Cindy and Yordanova, Galabina and Yuan, David and Stroe, Oana and Wood, Gemma and Laydon, Agata and {\v{Z}}{\'\i}dek, Augustin and Green, Tim and Tunyasuvunakool, Kathryn and Petersen, Stig and Jumper, John and Clancy, Ellen and Green, Richard and Vora, Ankur and Lutfi, Mira and Figurnov, Michael and Cowie, Andrew and Hobbs, Nicole and Kohli, Pushmeet and Kleywegt, Gerard and Birney, Ewan and Hassabis, Demis and Velankar, Sameer},
  journal={Nucleic Acids Research},
  volume={50},
  number={D1},
  pages={D439--D444},
  year={2022},
  publisher={Oxford University Press},
  doi={10.1093/nar/gkab1061}
}

Copy citation

proto-bio/proto-tools/proto_tools/tools/database_retrieval/alphafold_db

View source

Open Notebook

Open notebook

Coming soon!

Run this tool directly in Proto with no setup required.

Function	Description
run_alphafold_db_fetch()	Fetch predicted structure (PDB/mmCIF), per-residue pLDDT, and PAE matrix from the AlphaFold Prote…	Docs Source

Background

The AlphaFold Protein Structure Database (AFDB) (Varadi et al., 2022) is a freely accessible archive of protein structures predicted by AlphaFold2 (Jumper et al., 2021), maintained by Google DeepMind and EMBL-EBI. It hosts predicted atomic coordinates for the UniProt reference proteomes. Each entry carries a per-residue confidence score (pLDDT, 0 to 100) and a pairwise predicted aligned error (pAE) matrix in angstroms. AFDB hosts AlphaFold2 single-chain predictions only. Multi-chain complexes are produced by separate pipelines and are not part of this database.

Internally, the tool issues a GET request to the AFDB prediction endpoint at https://alphafold.ebi.ac.uk/api/prediction/{accession}, which returns a JSON list of prediction records. It selects the canonical record (AF-{accession}-F1) by default, or the record matching the requested isoform, then follows the URLs carried in that record: pdbUrl or cifUrl for the structure body, plddtDocUrl for the per-residue pLDDT array, paeDocUrl for the pAE matrix, and msaUrl for the input multiple-sequence alignment (an A3M file). The mean pLDDT is read from the record’s globalMetricValue field. Records and their provenance come directly from the official AlphaFold DB REST API. Results reflect the live database, which always serves the latest version of each prediction.

Learning Resources

• AlphaFold DB FAQ (EMBL-EBI) - official guidance on coverage, confidence interpretation, versioning, and downloads.
• AlphaFold DB API documentation (EMBL-EBI) - the REST API specification for prediction records and artifact URLs.
• AlphaFold Protein Structure Database (EMBL-EBI Training) - a guided introduction to the database and how to interpret its predictions.

Tools

AlphaFold DB Fetch (alphafold-db-fetch)

Retrieves a single AlphaFold DB prediction record by UniProt accession and returns the predicted sequence and its 1-indexed coordinates, gene and organism metadata, mean pLDDT, the AFDB artifact URLs, the full JSON record, and an optional parsed Structure carrying per-residue pLDDT and optional pAE on structure.metrics.

API Reference

Source

Input: AlphaFoldDBFetchInput

uniprot_id · string · required

UniProt accession to look up (e.g. ‘P04637’).

isoform · integer

Isoform number to select from the multi-record AFDB response. None (default) returns the canonical entry (AF-{accession}-F1); 2 selects AF-{accession}-2-F1, etc. AFDB typically exposes isoforms 2-9 for human proteins. Raises ValueError if the requested isoform doesn’t exist.

Source

Config: AlphaFoldDBFetchConfig

structure_format · enum · default: "pdb"

Structure file format.

Available options: pdb, cif

include_structure · boolean · default: "True"

If True (default), fetch the structure body and the per-residue pLDDT array, returning a parsed Structure on the output. Set to False for metadata-only probes (URLs, mean pLDDT, gene, sequence) — saves ~100-500 KB per call, meaningful for batch sweeps.

include_pae · boolean · default: "False"

If True, also fetch the PAE (predicted aligned error) matrix and attach it to output.structure.metrics["pae"]. Disabled by default — PAE files can be tens of MB for long proteins. No-op when include_structure=False.

include_msa · boolean · default: "False"

If True, fetch the A3M MSA used as input to the AlphaFold prediction. Disabled by default — A3M files can be hundreds of KB to several MB for highly conserved proteins.

verbose · integer · default: "0"

Verbosity level (0=quiet, 1=info, 2=debug, 3=raw subprocess stderr). True is coerced to 1 and False to 0.

device · string · default: "cpu"

Device to run the tool on.

timeout · integer · default: "600"

Maximum execution time in seconds. None waits indefinitely.

seed · integer

Random seed. When set, tools run reproducibly up to small GPU float noise (see BaseToolOutput.approx_equal), and the seed participates in cache keys. When None, cacheable seed-sensitive tools skip cache until seeded.

Source

Output: AlphaFoldDBFetchOutput

uniprot_accession · string · required

Primary UniProt accession that was looked up.

entry_id · string · required

AlphaFold entry identifier (e.g. ‘AF-P04637-F1’).

gene · string

Gene symbol from the AlphaFold record.

organism_scientific_name · string

Source organism scientific name.

tax_id · integer

NCBI taxonomy ID.

sequence · string · required

Amino-acid sequence covered by the prediction.

sequence_length · integer · required

Length of the predicted sequence.

sequence_start · integer · required

1-indexed start residue of the prediction (relative to the full UniProt sequence; >1 only for non-first fragments of very long proteins).

sequence_end · integer · required

1-indexed inclusive end residue of the prediction.

latest_version · integer · required

Latest version of the AlphaFold DB prediction (this is the version of the served prediction; AlphaFold DB always serves the latest).

model_created_date · string

ISO 8601 timestamp when this prediction was generated.

mean_plddt · number

Mean per-residue pLDDT for the prediction (AlphaFold DB’s globalMetricValue field). Always populated from the metadata response, regardless of include_structure; when include_structure=True it is also mirrored at structure.metrics["avg_plddt"].

pdb_url · string · required

URL to the PDB structure file on AlphaFold DB.

cif_url · string · required

URL to the mmCIF structure file on AlphaFold DB.

bcif_url · string

URL to the BinaryCIF structure file; None on legacy entries that predate the bcif export.

pae_doc_url · string · required

URL to the PAE JSON document on AlphaFold DB.

plddt_doc_url · string · required

URL to the per-residue pLDDT JSON document on AlphaFold DB.

pae_image_url · string · required

URL to the rendered PAE PNG on AlphaFold DB.

msa_url · string

URL to the MSA A3M used for prediction, when present.

am_annotations_url · string

AlphaMissense pathogenicity CSV URL (sequence coords); None for non-human or unscored entries.

am_annotations_hg19_url · string

AlphaMissense annotations on GRCh37.

am_annotations_hg38_url · string

AlphaMissense annotations on GRCh38.

sequence_checksum · string

CRC64 checksum of the predicted sequence.

structure · Structure

Parsed AlphaFold structure (PDB or mmCIF body in structure_format, b_factor_type=BFactorType.PLDDT) with an :class:AlphaFoldDBMetrics metrics container carrying avg_plddt, plddt_per_residue, and (when include_pae=True) pae. None when include_structure=False.

msa_a3m · string

A3M-format MSA contents used as input to the AlphaFold prediction. None when include_msa is False or when the entry has no associated MSA URL.

source_url · string · required

AlphaFold DB API URL used for the metadata lookup.

raw_entry · Dict[string, any]

Complete AlphaFold DB JSON record for advanced programmatic access.

Metrics

Metric	Type	Range	Availability
avg_plddt	float	0.0 to 100.0	always
plddt_per_residue	list[float]	0.0 to 100.0	always
pae	list[list[float]]	≥ 0.0	when include_pae=True

Applications

Use this to pull an AlphaFold-predicted structure into a pipeline when no experimental entry is needed: fetch a target by accession before inverse folding, docking, or binder design, screen accessions for AFDB coverage with metadata-only requests, or assess per-residue and pairwise confidence before structure-based work. The returned Structure feeds directly into structure-consuming tools such as TM-align, US-align, and structure scoring. The UniProt tool supplies the UniProt accession from a gene name and organism, and the PDB tool provides the experimental counterpart when one exists.

Usage Tips

• Coverage is broad but not universal. When AFDB has no prediction for an accession the tool raises ValueError. Catch that error and fall back to predicting the structure from sequence.
• A high mean_plddt can hide locally unreliable regions. Inspect the per-residue pLDDT on structure.metrics before trusting any specific residue.
• latest_version advances when AFDB refreshes a prediction. Cache it alongside any structure you persist and refetch when it moves past the cached value.
• Multiple records signal isoforms or fragments. The canonical record is selected by default and a warning lists the alternatives. To select a non-canonical isoform, pass the isoform input, and check entry_id, sequence_start, and sequence_end to confirm which record was returned.
• Low-confidence regions are usually real disorder, not a prediction error. Disordered or flexibly linked regions get very low per-residue confidence (pLDDT) and high predicted aligned error (pAE) between regions because they have no single fixed shape. Find those residue ranges from the per-residue pLDDT array and trim or down-weight just those residues. Do not throw away the whole prediction, because the confident domains are still reliable.

Toolkit Notes

These apply to every AlphaFold DB tool in this toolkit (alphafold-db-fetch).

• Requires network access. The tool calls the live AlphaFold DB REST API. It does not run offline and keeps no local copy of the database.
• Subject to AlphaFold DB rate limits. The EMBL-EBI API is unauthenticated and applies per-IP fair-use limits (EMBL-EBI Terms of Use). Space out high-volume requests.

Example notebook: See the full working example for a copy-paste-ready walkthrough.
